Home office interactive classroom teaching board infrared screen writing finger pen touch screen whiteboard
Quick details:
1.Reasonable use of electronic whiteboard, optimize classroom introduction, stimulate students'interest in learning
2.The use of electronic whiteboard highlights the difficult points, exercise the students of a variety of thinking
3.Using electronic whiteboard to enhance classroom interaction
4.Make full use of the storage function of the Electronic Whiteboard, make the classroom teaching process reappear,
improve the classroom teaching efficiency
5.Using templates to deepen classroom training and improve the quality of exercises.
Specification:
65inch interactive touch screen
| | | | |
| | | Backlight type | |
| | | | |
| | | LCD screen resolution | 1920(H)×1080(V) |
| | | | |
| | | Viewing angle | 165/165/150/150(L/R/U/D) |
| | | | |
| LCD | screen | Colour | 16.7M |
| | |
| parameters | Brightness | 400cd/m2 |
| | | | |
| | | Aspect ratio | 5000:1 |
| | | | |
| | | Response time | 4ms |
| | | | |
| | | Active area | 1430(H)×804mm(V) |
| | | | |
| | | Identification | Infrared identification |
| | | | |
| | | Touch points | 6 or 10 points touch |
| | | | |
| | | Anti-light | Light heart of the various angles of the screen can |
| | | interference | be used normally |
| Touch screen | Writing way | finger,Pen,diameter >5mm Opaque object |
| | |
| parameters | | |
| Touch precision | More than 95% of the touch area is ± 2mm |
| | |
| | | | |
| | | communication | Full speed USB2.0/3.0 |
| | | method | |
| | | Writing screen | Physical steel mode 7 explosion - proof |
| | | surface hardness | |
| | | Touch screen life | More than 80000 hours |
| | | | |
| | PC | CPU | Standard Intel I3 Dual Core 2.4G |
| | | | |
| | RAM | 4G DDR3 |
| | | |
| | Hard disk | 500GB hard disk |
| | | |
| | Network card | 100/1000M Gigabit Ethernet |
| | | |
| | | Coaxial antenna port: a group |
| | | |
| | | Composite video (CVBS) input port: two groups |
| | | |
| | | Computer VGA port: a group |
| | Video Input | |
| | Component Video interface: a group |
| | | |
| | | Multimedia USB interface: three groups |
| | | |
| | | HD interface (HDMI): a group |
| Hardware | | |
| | MIC input |
| parameters | | |
| Touch screen USB input | Touch screen USB:a group |
| |
| | |
| | | |
| | | Composite Video (CVBS) Audio Input Port: One group |
| | | |
| | Audio input | Computer audio input interface: a group |
| | |
| | | |
| | | YPbPr audio input port: a group |
| | | |
| | Video output | Composite video audio output port: a group |
| | | |
| | | Left / Right Channel CVBS Output Port: One group |
| | Audio output | |
| | Ear audio output: a group |
| | |
| | | |
| | | Image format:PAL |
| | | |
| | TV system | Voice format:BG；DK；I;MN |
| Characteristic | |
| | Decoding: 3D digital comb filter, 3D image motion noise reduction, |
| parameter | | 3D motion adaptive comb filter, etc. |
| | |
| | Speaker | Speaker type: front speakers |
| | |
| | characteristics | Speaker power: 10W × 2 |
| | | |
| Input voltage | AC:100～240 V 50/60 Hz |
| | | |
| Power | ≤180W |
| | | |
| Standby Power consumption | ＜0.5W |
| | | |
| Net weight | 42kg |
| | | |
| Gross weight | 51kg |
| | | |
| Product dimension(L*W*T) | 1469X887X63MM |
| | | |
| Carton packing size(L*W*T) | 1575X1000X175MM |
| | | |
| Wall mount size (L*W) | 600X510MM |
| | | |
| environment | Relative humidity≤80﹪ |
| | | |
Storage temperature -10～+60℃
Working temperature 0～+40℃
